Description
Specifications
Processor
- Processor manufacturer: Intel
- Processor socket: LGA 2066 (Socket R4)
- Compatible processor series: Intel® Core™ X-series
- Maximum number of SMP processors: 1
- Supported processor sockets: LGA 2066
Memory
- Supported memory types: DDR4-SDRAM
- Number of memory slots: 8
- Memory slots type: DIMM
- ECC сompatibility: Non-ECC
- Supported memory clock speeds: 2133, 2400, 2666, 2800, 2933, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3733, 3800, 3866, 4000, 4133, 4266 MHz
- Maximum internal memory: 256 GB
- Unbuffered memory: Yes
Storage controllers
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
- RAID support: Yes
- RAID levels: 0, 1, 5, 10
Graphics
- Parallel processing technology support: 2-Way SLI, 3-Way CrossFireX, 3-Way SLI, Quad-GPU CrossFireX, Quad-GPU SLI
- On-board graphics card: No
Internal I/O
- USB 2.0 connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Number of SATA III connectors: 8
- Front panel audio connector: Yes
- Front panel connector: Yes
- ATX Power connector (24-pin): Yes
- Number of EATX power connectors: 2
- CPU fan connector: Yes
- Number of chassis fan connectors: 2
- Number of COM connectors: 1
- Thunderbolt headers: 1
Rear panel I/O ports
- USB 2.0 ports quantity: 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- Ethernet LAN (RJ-45) ports: 1
- PS/2 ports quantity: 1
- Headphone outputs: 1
- Microphone in: Yes
- S/PDIF out port: Yes
Network
- Ethernet LAN: Yes
- Ethernet interface type: Gigabit Ethernet
- LAN controller: Intel® I219-V
- Wi-Fi: No
Features
- Motherboard chipset: Intel® X299
- Audio chip: Realtek ALC S1220A
- Audio output channels: 7.1 channels
- Product colour: Black, Silver
- Component for: PC
- Motherboard form factor: ATX
- Motherboard chipset family: Intel
- Cooling type: Passive
- Power source type: ATX
- Windows operating systems supported: Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 10 x64
Expansion slots
- PCI Express x1 (Gen 3.x) slots: 2
- PCI Express x16 (Gen 3.x) slots: 3
- Number of M.2 (M) slots: 3
BIOS
- BIOS type: UEFI AMI
- BIOS memory size: 128 Mbit
- ACPI version: 6.1
- System management BIOS (SMBIOS) version: 3.1
Processor special features
- Intel Extreme Memory Profile (XMP): Yes
- Intel® Optane™ Memory Ready: Yes
Logistics data
- Harmonized System (HS) code: 84733020
Weight & dimensions
- Width: 305 mm
- Depth: 244 mm
Packaging content
- Drivers included: Yes
Other features
- HDD size: 2.5/3.5"
- Processor lithography: 14 nm
- Utilities included: Yes
