Name: LevelOne 10-Port Web Smart Gigabit PoE Switch, 8 PoE Outputs, 2 x Gigabit SFP, 70W
Brand: LEVELONE
Price: 321.56 EUR
Availability: InStock

LevelOne 10-Port Web Smart Gigabit PoE Switch, 8 PoE Outputs, 2 x Gigabit SFP, 70W

321.56 €

253.20 € without VAT

Description

8 x 10/100/1000 RJ-45, 2 x 100/1000 SFP, 16 MB, 20Gbps, 8K, QoS, 2000 g

Specifications

Management features

Switch type: Managed
Switch layer: L2/L3/L4
Quality of Service (QoS) support: Yes
Web-based management: Yes
ARP inspection: Yes
System event log: Yes
MIB support: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 2

Network

Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.
10G support: No
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Rate limiting: Yes
Spanning tree protocol: Yes
Fast leave: Yes
VLAN support: Yes
Virtual LAN features: Tagged VLAN, Port-based VLAN

Optical fiber

Fiber ethernet cabling technology: 1000BASE-X

Data transmission

Switching capacity: 20 Gbit/s
Forwarding rate: 14.9 Mpps
MAC address table: 8000 entries
Store-and-forward: Yes
Number of queues: 8
Jumbo frames support: Yes
Jumbo frames: 10000
Packet buffer memory: 4.1 MB

Security

DHCP features: DHCP client
Access Control List (ACL): Yes
Access Control List (ACL) ingress: 256
IGMP snooping: Yes
Security algorithms: SSH, SSH-2, SSL/TLS
MAC address filtering: Yes
Static port security: Yes
Loop protection: Yes
BPDU filtering/protection: Yes
Root protection: Yes
Password protection: Yes
DoS attack prevention: Yes
Authentication type: HWTACACS+, RADIUS
CPU defense: Yes
Queue scheduling algorithms: Weighted Round Robin (WRR)
Neighbor discovery snooping: Yes

Multicast features

Multicast Listener Discovery (MLD) snooping: Yes

Protocols

Management protocols: SNMP v1/v2c/v3, Telnet
IPv4 & IPv6 features: IPv6 ping, IPv6 tracert, IPv6 Telnet, Dual stack IPv4/IPv6

Design

Rack mounting: Yes
Product colour: Black
Reset button: Yes
LED indicators: Activity, Link, Power, System
Safety: UL

Performance

Internal memory: 16 MB
Noise level: 0 dB
Firmware upgradeable: Yes
Plug and Play: Yes
Mean time between failures (MTBF): 118824 h

Power

AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (typical): 80 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 8
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 70 W

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 267.95 BTU/h

Weight & dimensions

Width: 294 mm
Depth: 180 mm
Height: 44 mm
Weight: 2 kg

Packaging content

Cables included: AC
Quick start guide: Yes
Rack mount kit: Yes

Packaging data

Package type: Box
Resource CD: Yes
Package width: 375 mm
Package depth: 270 mm
Package height: 85 mm
Package weight: 2.18 kg

Certificates

Certification: CE class A, FCC, VCCI, BSMI

Logistics data

Country of origin: China
Harmonized System (HS) code: 85176990
