Description
Specifications
Storage
- Storage drive interface: Serial ATA
- Storage drive sizes supported: 3.5"
- RAID support: Yes
- RAID levels: 0, 1, JBOD
- Online RAID migration: Yes
- Supported file systems: FAT32, HFS+, NTFS, exFAT, ext3, ext4
- Storage drives installed: No
- Total installed storage capacity: 0 TB
- Number of storage drives supported: 4
- Installed storage drive type: No
- Supported storage drive types: HDD & SSD
- Bad block scan: Yes
Processor
- Processor manufacturer: Realtek
- Processor family: Realtek
- Processor model: RTD1619B
- Processor frequency: 1.7 GHz
- Processor cores: 4
Memory
- Internal memory: 1 GB
- Internal memory type: DDR4
- Flash memory: 8000 MB
Network
- Ethernet LAN: Yes
- Ethernet LAN data rates: 100, 1000, 2500 Mbit/s
- DHCP server: Yes
- Jumbo frames support: Yes
- iSCSI support: Yes
- Wake-on-LAN ready: Yes
- Supported network protocols: Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog
Ports & interfaces
- USB port: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- Ethernet LAN (RJ-45) ports: 1
Design
- Chassis type: Tower
- Cooling type: Active
- Product colour: Black
- Number of fans: 1 fan(s)
- Fan diameter: 12 cm
- LED indicators: Yes
Performance
- Type: NAS
- Device class: Home & Home Office
- Backup function: Yes
- Number of users: 4096 user(s)
- Noise level: 19.7 dB
- Snapshot: Yes
- Web-based management: Yes
- Security algorithms: 256-bit AES, HTTPS, SNMP, SSH
- Access Control List (ACL): Yes
- Browser supported: Firefox, Chrome, Safari, Microsoft Edge
- System log: Yes
- S.M.A.R.T. support: Yes
Software
- Operating system installed: ADM
- Operating system version: 5.0
- Windows operating systems supported: Windows 10, Windows 11
- Linux operating systems supported: Yes
- Server operating systems supported: Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022
Power
- Power supply unit (PSU) capacity: 65 W
- Power consumption (typical): 22.8 W
- AC input voltage: 100 - 240 V
Weight & dimensions
- Width: 164 mm
- Depth: 218 mm
- Height: 165 mm
- Weight: 1.57 kg
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 5 - 95%
- Storage temperature (T-T): -20 - 70 °C
