Description
TP-Link Omada ES208GP, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, DIN rail
Specifications
Management features
- Switch type: Managed
- Switch layer: L2
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- Cloud-managed: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 8
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
- Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
- 10G support: No
- Port mirroring: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Auto MDI/MDI-X: Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
- Auto-negotiation: Yes
- VLAN support: Yes
- Virtual LAN features: MTU VLAN, Port-based VLAN, Tagged VLAN
- Number of VLANs: 4000
Optical fiber
- Transmission distance (max): 0.25 km
Data transmission
- Switching capacity: 16 Gbit/s
- Forwarding rate: 11.904 Mpps
- MAC address table: 8000 entries
- Store-and-forward: Yes
- Jumbo frames support: Yes
- Jumbo frames: 15000
- Packet buffer memory: 0.5 MB
Security
- DHCP features: DHCP client
- IGMP snooping: Yes
- Loop protection: Yes
Multicast features
- Multicast support: Yes
Design
- Rack mounting: Yes
- Form factor: DIN rail
- Product colour: Black
- LED indicators: Yes
Power
- Power source: DC
- DC input voltage: 53 V
- Input current: 1.31 A
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) type supported: PoE+
- Power over Ethernet plus (PoE+) ports quantity: 8
- Total Power over Ethernet (PoE) budget: 64 W
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
- Width: 158 mm
- Depth: 100.7 mm
- Height: 25.4 mm
Packaging content
- Cables included: Power
- Quick start guide: Yes
Certificates
- Compliance certificates: CE, Federal Communications Commission (FCC), RoHS
