Description
Specifications
Features
- Type: AV transmitter & receiver
- Maximum resolution: 1920 x 1200 pixels
- Cable types supported: Cat5e
- Maximum transfer distance: 60 m
- Supported video modes: 1080i, 1080p
- Supported graphics resolutions: 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
- Bandwidth: 225 MHz
- HDCP: Yes
- Material: Metal
- Impedance: 100 Ω
- Product colour: Black
Ports & interfaces
- Connectivity technology: Wired
- Ethernet LAN: Yes
- RJ-45 input ports: 2
- RJ-45 output ports: 2
- DVI input ports: 2
- DVI output ports: 2
- Video in: 1 x DVI-D
- Video out: 1 x DVI-D
- Audio input: 1
- Audio output: 1
Power
- Power consumption (max): 2.05 W
- Power consumption (transmitter) (max): 1.56 W
- Power consumption (receiver) (max): 0.76 W
Operational conditions
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
Weight & dimensions
- Weight: 490 g
- Receiver dimensions (WxDxH): 56 x 91.3 x 24 mm
- Receiver weight: 170 g
- Transmitter dimensions (WxDxH): 56 x 91.3 x 24 mm
- Transmitter weight: 170 g
Packaging data
- Quantity per pack: 2 pc(s)
- Package width: 59 mm
- Package depth: 239 mm
- Package height: 160 mm
- Package weight: 660 g
Packaging content
- AC adapter included: Yes
- Manual: Yes
- Grounding wire: Yes
- Mounting kit: Yes
Technical details
- Compliance certificates: RoHS
Logistics data
- Master (outer) case width: 315 mm
- Master (outer) case length: 490 mm
- Master (outer) case height: 338 mm
- Master (outer) case gross weight: 14 kg
- Master (outer) case net weight: 9.8 kg
- Products per master (outer) case: 20 pc(s)
