Description
Specifications
Processor
- Processor manufacturer: Intel
- Processor family: Intel® Core™ i5
- Processor generation: Intel® Core™ i5 (14th gen)
- Processor model: i5-14500T
- Processor cores: 14
- Processor threads: 20
- Processor boost frequency: 4.8 GHz
- Performance cores: 6
- Efficient cores: 8
- Performance-core Max Turbo Frequency: 4.8 GHz
- Efficient-core Max Turbo Frequency: 3.4 GHz
- Performance-core base frequency: 1.7 GHz
- Efficient-core base frequency: 1.2 GHz
- Processor cache: 24 MB
- Processor cache type: Smart Cache
- Number of processors installed: 1
- Processor base power: 35 W
- Maximum turbo power: 92 W
Memory
- Internal memory: 8 GB
- Maximum internal memory: 64 GB
- Internal memory type: DDR5-SDRAM
- Memory layout (slots x size): 1 x 8 GB
- Memory slots: 2x SO-DIMM
Storage
- Total storage capacity: 512 GB
- Storage media: SSD
- Optical drive type: No
- Total SSDs capacity: 512 GB
- Number of SSDs installed: 1
- SSD capacity: 512 GB
- SSD interface: PCI Express
- NVMe: Yes
- SSD form factor: M.2
- SSD performance class: 35
- M.2 SSD size: 2230 (22 x 30 mm)
Graphics
- Discrete graphics card: No
- On-board graphics card: Yes
- Discrete graphics card model: Not available
- On-board GPU manufacturer: Intel
- On-board graphics card family: Intel® UHD Graphics
- On-board graphics card model: Intel UHD Graphics 770
Network
- Ethernet LAN: Yes
- Ethernet LAN data rates: 10, 100, 1000 Mbit/s
- Wi-Fi: Yes
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- Wi-Fi standards: 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax)
- WLAN controller manufacturer: Intel
- WLAN controller model: Intel Wi-Fi 6E AX211
- Antenna type: 2x2
- Bluetooth: Yes
Ports & interfaces
- DisplayPort version: 1.4a
- Ethernet LAN (RJ-45) ports: 1
- Combo headphone/mic port: Yes
- DC-in jack: Yes
- USB 2.0 ports quantity: 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- PowerShare: Yes
- Number of USB ports with PowerShare support: 1
- HDMI ports quantity: 1
- HDMI version: 1.4b
- DisplayPorts quantity: 1
Design
- Chassis type: MFF
- Placement supported: Horizontal/Vertical
- Cable lock slot: Yes
- Cable lock slot type: Kensington
- Product colour: Black
Performance
- Market positioning: Business
- Motherboard chipset: Intel Q670
- Audio chip: Realtek ALC3204
- Built-in speaker(s): Yes
- Number of speakers: 1
- Password protection: Yes
- Trusted Platform Module (TPM): Yes
- Trusted Platform Module (TPM) version: 2.0
- Product type: Mini PC
Software
- Operating system installed: Windows 11 Pro
- Operating system architecture: 64-bit
- Operating system language: English, Spanish, French, Italian, Portuguese
- Trial software: Activate Your Microsoft 365 For A 30 Day Trial
Power
- Power supply: 90 W
- Power supply input voltage: 100 - 240 V
- Power supply input frequency: 50/60 Hz
Operational conditions
- Operating temperature (T-T): 10 - 35 °C
- Storage temperature (T-T): -40 - 65 °C
- Operating relative humidity (H-H): 20 - 80%
- Storage relative humidity (H-H): 5 - 95%
- Operating altitude: -15.2 - 3048 m
- Non-operating altitude: -15.2 - 10668 m
- Operating vibration: 0.26 G
- Non-operating vibration: 1.37 G
- Operating shock: 40 G
- Non-operating shock: 105 G
Sustainability
- Sustainability compliance: Yes
- Sustainability certificates: TCO, ENERGY STAR, EPEAT Climate +
- Doesn't contain: PVC/BFR
Weight & dimensions
- Width: 36 mm
- Depth: 178 mm
- Height: 182 mm
Packaging content
- Display included: No
- Cables included: AC
- Power cable length: 1.8 m
Carbon footprint
- Total carbon footprint (kg of CO2e): 91
- Carbon emissions, manufacturing (kg of CO2e): 59
- Carbon emissions, logistics (kg of CO2e): 2
- Carbon emissions, energy usage (kg of CO2e): 28
- Carbon emissions, end-of-life (kg of CO2e): 1
- Total carbon emissions, w/o use phase (kg of CO2e): 62
- PAIA version: GaBi version 1, 2024
