Description
Specifications
Storage
- Storage drive capacity: 0 GB
- Storage drive interface: Serial ATA II, Serial ATA III
- Supported storage drive interfaces: Serial ATA II, Serial ATA III
- Storage drive size: 2.5/3.5"
- Storage drive sizes supported: 2.5, 3.5"
- RAID support: Yes
- RAID levels: 0, 1, 5, 6, 10, 50, 60, JBOD
- Online RAID migration: Yes
- Online RAID expansion: Yes
- RAID rebuild: Yes
- Hot-swap drive bays: Yes
- Supported file systems: FAT32, HFS+, NTFS, ext3, ext4
- Storage drives installed: No
- Total installed storage capacity: 0 TB
- Number of storage drives supported: 12
- Installed storage drive type: No
- Supported storage drive types: HDD & SSD
- Bad block scan: Yes
- Disk roaming: Yes
Processor
- Processor manufacturer: AMD
- Processor generation: AMD Ryzen Embedded V1000 Series
- Processor family: Ryzen Embedded
- Processor model: V1500B
- Processor frequency: 2.2 GHz
- Processor cores: 4
- Processor threads: 8
- L2 cache: 2 MB
- L3 cache: 4 MB
Memory
- Internal memory: 8 GB
- Internal memory type: DDR4
- Maximum RAM supported: 32 GB
- Memory slots: 2
- Memory form factor: DIMM
- Flash memory: 5000 MB
Network
- Ethernet LAN: Yes
- Ethernet LAN data rates: 100, 1000, 2500 Mbit/s
- DHCP client: Yes
- DHCP server: Yes
- Jumbo frames support: Yes
- iSCSI support: Yes
- Wake-on-LAN ready: Yes
- Supported network protocols: PPTP, L2TP/IPSec, OpenVPN, QBelt
- Link aggregation: Yes
- Load balancing system: Yes
- Dynamic DNS (DDNS): Yes
- WLAN adapter supported: Yes
Ports & interfaces
- USB port: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
- Ethernet LAN (RJ-45) ports: 2
Design
- Chassis type: Rack (2U)
- Cooling type: Active
- Product colour: Aluminium, Black
- Number of fans: 2 fan(s)
- Fan diameter: 8 cm
- Fan diameter 2: 8 cm
Performance
- Buzzer: Yes
- Multilingual support: Yes
- Snapshot: Yes
- Security algorithms: 256-bit AES, FIPS 140-2, HTTPS, SNMPv2, SNMPv3, SSL/TLS
- Access Control List (ACL): Yes
- Reset button: Yes
- On/off switch: Yes
- Built-in FTP server: Yes
- Browser supported: Apple Safari 7+, Google Chrome, Mozilla Firefox
- System log: Yes
- Hot spare: Yes
- Disk scan: Yes
- S.M.A.R.T. support: Yes
- Share folder: CIFS/SMB
- Universal Plug and Play (UPnP): Yes
- USB copy function: Yes
- Type: NAS
- Device class: Small & Medium Business
- Backup function: Yes
- Backup features: Cloud, iSCSI LUN
Software
- Operating system installed: QNAP QTS
- Operating system version: 5.0.0
- Windows operating systems supported: Windows 10, Windows 7, Windows 8
- Linux operating systems supported: Yes
- Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Ma
- Server operating systems supported: Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Win
- Other operating systems supported: Solaris 10
Power
- Power supply location: Built-in
- Power supply unit (PSU) capacity: 300 W
- Number of power supply units: 2
- Power consumption (typical): 78.92 W
- Power consumption (sleep): 43.67 W
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
Weight & dimensions
- Width: 482 mm
- Depth: 425 mm
- Height: 89 mm
- Weight: 9.69 kg
- Package weight: 14.6 kg
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 5 - 95%
- Storage temperature (T-T): -20 - 70 °C
Logistics data
- Harmonized System (HS) code: 84714100
