Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L2
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 12
- Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
- SFP+ module slots quantity: 2
- Power connector: DC-in jack
Network
- Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 80
- 10G support: Yes
- Broadcast storm control: Yes
- VLAN support: Yes
- Virtual LAN features: Port-based VLAN
- Number of VLANs: 64
Data transmission
- Switching capacity: 240 Gbit/s
- MAC address table: 32000 entries
- Store-and-forward: Yes
- Jumbo frames support: Yes
- Jumbo frames: 9000
- Packet buffer memory: 3 MB
Security
- DHCP features: DHCP client
- IGMP snooping: Yes
- MAC address filtering: Yes
Design
- Rack mounting: Yes
- Form factor: 1U
- Product colour: Blue, Grey
- LED indicators: Yes
- Number of fans: 2 fan(s)
Performance
- Mean time between failures (MTBF): 1113477 h
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Input current: 2 A
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 70 °C
- Operating relative humidity (H-H): 0 - 90%
- Storage relative humidity (H-H): 0 - 95%
- Heat dissipation: 261.38 BTU/h
Weight & dimensions
- Width: 328 mm
- Depth: 204 mm
- Height: 43 mm
- Weight: 2.51 kg
Sustainability
- Sustainability certificates: ENERGY STAR
Certificates
- Certification: 47 CFR FCC, ICES-003:2016, ANSI C63.4:2014, EN55032:2012+AC:2013, EN 55024:2010, EN 61000-3-2:2014, EN 6100-3-3:2013, AS/NZS CIS
Logistics data
- Harmonized System (HS) code: 85176990
