Hewlett Packard Enterprise Aruba Instant On 1430 8G Class4 PoE 64W Unmanaged L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) White
Hewlett Packard Enterprise Aruba Instant On 1430 8G Class4 PoE 64W, Unmanaged, L2, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE).
More infoBrand: HEWLETT PACKARD ENTERPRISE
170.08 €
141.74 €
without VAT
Stock available: 7 units.
Get it
on the
September 24
/
September 25
SKU:
94716
PRC:
381969
EAN:
190017601762
PN:
R8R46A#ABB
Description
The Hewlett Packard Enterprise Aruba Instant On 1430 8G unmanaged switch offers Gigabit Ethernet (10/100/1000) connectivity for small networks that need simplicity. It incorporates 8 RJ-45 ports that allow computers, access points and Power over Ethernet compatible devices to be connected. It operates at L2 layer and supports Quality of Service (QoS), flow control, auto-detection and full duplex and half duplex transmission. Its performance reaches 11.9 Mpps, with a MAC address table of 8192 entries and Jumbo Frames support. Latency is 1.8 µs at 1 Gbps and 2.7 µs at 10-100 Mbps. It complies with IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az and IEEE 802.3i standards, and works with 10BASE-T, 100BASE-TX and 1000BASE-T copper cabling. It has a white colour and dimensions of 177 x 37 x 150 mm (width x height x depth), with a weight of 770 g.
Specifications
Management features
- Switch type: Unmanaged
- Switch layer: L2
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 8
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
- 10G support: No
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Full duplex: Yes
- Half duplex: Yes
- Flow control support: Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
- Auto-sensing: Yes
Data transmission
- Switching capacity: 16 Gbit/s
- Throughput: 11.9 Mpps
- MAC address table: 8192 entries
- Latency (10-100 Mbps): 2.7 µs
- Latency (1 Gbps): 1.8 µs
- Jumbo frames support: Yes
- Packet buffer memory: 2 MB
Design
- Product colour: White
Power
- Power source: AC
- Power supply included: Yes
- Number of power supply units: 1
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- Power consumption (max): 90 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Total Power over Ethernet (PoE) budget: 64 W
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 15 - 95%
- Storage relative humidity (H-H): 15 - 90%
Weight & dimensions
- Width: 177 mm
- Depth: 150 mm
- Height: 37 mm
- Weight: 770 g
