Dahua Technology PoE PFS3010-8ET-96-V2 network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
More info
Brand: DAHUA TECHNOLOGY
69.44 €Stock available: 0 units.
Unavailable
SKU:
97039
PRC:
405609
EAN:
6923172507556
PN:
DH-PFS3010-8ET-96
Description
The Dahua Technology PFS3010-8ET-96-V2 unmanaged switch comes in black with a weight of 500 g and is designed to expand small and medium-sized networks. It offers ten basic RJ-45 Ethernet switching ports, of which eight are copper Fast Ethernet and two are Gigabit Ethernet, with transfer speeds of 10, 100 and 1000 Mbit/s. Its eight Power over Ethernet ports allow network devices such as IP cameras to be powered without the need for an additional power outlet, with a PoE budget of 96 W. Power is supplied via a direct current power supply, with an input voltage of 48 to 57 V and an energy consumption of 90 W. It is compatible with the IEEE 802.3, 802.3ab, 802.3af, 802.3at, 802.3u and 802.3x network standards, which facilitates its integration into existing installations. Its switching capacity reaches 5.6 Gbit/s and the forwarding rate is 4.17 Mpps.
Specifications
Management features
- Switch type: Unmanaged
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 10
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Fast Ethernet (copper) ports quantity: 8
- Gigabit Ethernet (copper) ports quantity: 2
Network
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3by, IEEE 802.3u, IEEE 802.3x
- 10G support: No
- Ethernet LAN data rates: 10,100,1000 Mbit/s
Data transmission
- Switching capacity: 5.6 Gbit/s
- Forwarding rate: 4.17 Mpps
- MAC address table: 8000 entries
- Packet buffer memory: 4 MB
Design
- Product colour: Black
Power
- Power source: DC
- DC input voltage: 48 - 57 V
- Power consumption (typical): 90 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) ports quantity: 8
- Total Power over Ethernet (PoE) budget: 96 W
Operational conditions
- Operating temperature (T-T): -10 - 55 °C
- Storage temperature (T-T): -20 - 70 °C
- Operating relative humidity (H-H): 5 - 95%
- Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
- Weight: 500 g
Packaging data
- Package width: 190 mm
- Package depth: 100 mm
- Package height: 30 mm
- Package weight: 1.32 kg
