Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L3
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- Traffic classification: Yes
- ARP inspection: Yes
- Configuring Location Settings (CLI): Yes
- MIB support: BRIDGE-MIB, CISCO-BRIDGE-EXT-MIB, CISCO-BULK-FILE-MIB, CISCO-CABLE-DIAG-MIB, CISCO-CALLHOME-MIB, CISCO-CEF-MIB, CISCO-CIRCUIT-IN
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 48
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 4
- Power connector: AC-in jack
Network
- Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3
- 10G support: Yes
- Copper ethernet cabling technology: 10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T
- Full duplex: Yes
- IP routing: Yes
- Routing entries: 3000
- Flow control support: Yes
- Spanning tree protocol: Yes
- VLAN support: Yes
- Number of VLANs: 4096
Data transmission
- Switching capacity: 104 Gbit/s
- Forwarding rate: 77.38 Mpps
- MAC address table: 16000 entries
- Jumbo frames support: Yes
- Jumbo frames: 9198
- Packet buffer memory: 6 MB
Security
- Access Control List (ACL): Yes
- Security algorithms: 128-bit AES
Multicast features
- Multicast support: Yes
- Multicast MAC address table: 1000 entries
- IPv4 multicast entries: 3000
- IPv6 multicast entries: 1500
Protocols
- Management protocols: SNMPv1/v2c/v3
- Routing protocols: CDP, EIGRP, OSPF, RIP, VRRP
Design
- Product colour: Grey
- Electromagnetic compatibility: 47 CFR Part 15, CISPR 22 Class A, CISPR 32 Class A, CNS 13438, EN 300 386, EN 55022 Class A, EN 55032 Class A, EN61000-3-2, EN61
Performance
- Memory type: DRAM
- Internal memory: 2000 MB
- Flash memory: 4000 MB
Power
- Power supply included: Yes
- Redundant power supply (RPS) support: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Input current: 1.6 - 0.7 A
- Power consumption (typical): 125 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): -5 - 45 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 5 - 90%
- Operating altitude: 0 - 3000 m
Weight & dimensions
- Width: 445 mm
- Depth: 288 mm
- Height: 44 mm
Packaging data
- Package type: Box
Certificates
- Certification: RoHS, IEC 60950-1, UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950.1
Logistics data
- Harmonized System (HS) code: 85176990
