Allied Telesis GS980MX Managed L3 Gigabit Ethernet (10/100/1000) 1U Grey
More info
Brand: ALLIED TELESIS
1,713.72 €
SKU:
117013
PRC:
452107
EAN:
767035216775
PN:
AT-GS980MX/52-50
Description
AT-GS980MX - 48-port 10/100/1000T stackable switch with 4 SFP+ ports and a single fixed power supply, European power cord
Specifications
Management features
- Switch type: Managed
- Switch layer: L3
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- Traffic classification: Yes
- Traffic shaping: Yes
- Configuring Location Settings (CLI): Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 48
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Installed SFP+ modules quantity: 4
Network
- Networking standards: IEEE 802.1x, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
- 10G support: Yes
- Port mirroring: Yes
- Full duplex: Yes
- IP routing: Yes
- Policy-based routing: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Spanning tree protocol: Yes
- VLAN support: Yes
- Virtual LAN features: Port-based VLAN, Private VLAN, Voice VLAN
- Number of VLANs: 4094
Data transmission
- Switching capacity: 176 Gbit/s
- Forwarding rate: 130.9 Mpps
- MAC address table: 16000 entries
- Latency (10-100 Mbps): 8.29 µs
- Latency (1 Gbps): 7.63 µs
- Latency (10 Gbps): 1.63 µs
- Jumbo frames support: Yes
Security
- DHCP features: DHCP client, DHCP snooping
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- MAC address filtering: Yes
- SSH/SSL support: Yes
- Loop protection: Yes
- BPDU filtering/protection: Yes
- Authentication: MAC-based authentication
Multicast features
- Multicast support: Yes
Protocols
- Management protocols: SNMP
Design
- Rack mounting: Yes
- Stackable: Yes
- Form factor: 1U
- Product colour: Grey
Performance
- Memory type: DDR3-SDRAM
- Internal memory: 16384 MB
- Flash memory: 256 MB
- Noise level: 42 dB
Power
- Power source: AC
- Power supply included: Yes
- Power consumption (max): 60 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -25 - 70 °C
- Operating relative humidity (H-H): 5 - 90%
- Storage relative humidity (H-H): 5 - 95%
- Operating altitude: 0 - 3000 m
- Non-operating altitude: 0 - 4000 m
- Heat dissipation: 205 BTU/h
Weight & dimensions
- Width: 441 mm
- Depth: 323 mm
- Height: 44 mm
- Weight: 4.8 kg
Packaging content
- Cables included: AC
Packaging data
- Package width: 563 mm
- Package depth: 534 mm
- Package height: 128 mm
- Package weight: 6.8 kg
