Description
Specifications
Management features
- Switch type: Unmanaged
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 16
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
- Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
- 10G support: No
- Cable types supported: Cat3, Cat4, Cat5, Cat5e, Cat6
- Flow control support: Yes
- Auto MDI/MDI-X: Yes
- Active link detection: Yes
Data transmission
- Switching capacity: 32 Gbit/s
- Forwarding rate: 23.8 Mpps
- MAC address table: 8000 entries
- Jumbo frames support: Yes
- Jumbo frames: 9216
- Packet buffer memory: 0.5 MB
Design
- Rack mounting: Yes
- LED indicators: Activity, Link, Power
- Wall mountable: Yes
- Electromagnetic compatibility: CE, FCC, RCM, ICES-003, BSMI
Performance
- Fanless: Yes
- Mean time between failures (MTBF): 1156942 h
Power
- Power supply included: Yes
- Number of power supply units: 1
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption (max): 10 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 10 - 95%
- Heat dissipation: 32.86 BTU/h
Weight & dimensions
- Width: 215 mm
- Depth: 133 mm
- Height: 42 mm
- Weight: 900 g
Packaging content
- Cables included: AC
- Rack mount kit: Yes
Packaging data
- Package type: Box
Certificates
- Certification: LVD, BSMI RoHS, REACH
Logistics data
- Harmonized System (HS) code: 85176990
