Description
Specifications
Management features
- Switch type: Unmanaged
- Switch layer: L2
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 16
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 16
Network
- Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
- 10G support: No
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Cable types supported: Cat3, Cat4, Cat5, Cat5e, Cat6
- Port mirroring: Yes
- Full duplex: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Rate limiting: Yes
- Auto MDI/MDI-X: Yes
- Auto-negotiation: Yes
- Cable length detection: Yes
- VLAN support: Yes
- Virtual LAN features: Tagged VLAN, Protocol-based VLAN
- Number of VLANs: 32
Data transmission
- Switching capacity: 32 Gbit/s
- Forwarding rate: 23.81 Mpps
- MAC address table: 8000 entries
- Store-and-forward: Yes
- Number of queues: 4
- Jumbo frames support: Yes
- Jumbo frames: 10000
- Packet buffer memory: 4.1 MB
Security
- IGMP snooping: Yes
- Loop protection: Yes
Design
- Rack mounting: No
- Product colour: Black
- Housing material: Metal
- LED indicators: Yes
Performance
- Plug and Play: Yes
Power
- Power source: DC
- Power supply included: Yes
- Input current: 1 A
- Input voltage: 12 V
- Power consumption (max): 9.19 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
- Heat dissipation: 31.68 BTU/h
Weight & dimensions
- Width: 286 mm
- Depth: 111.7 mm
- Height: 25.4 mm
Packaging content
- Cables included: AC
- Quick start guide: Yes
Packaging data
- AC adapter included: Yes
- Rubber feet: Yes
- Package width: 170 mm
- Package depth: 412 mm
- Package height: 70 mm
- Package weight: 1.36 kg
Certificates
- Certification: FCC, CE, RoHS
Logistics data
- Harmonized System (HS) code: 85176990
