StarTech.com 2-Port Gigabit PCIe Network Adapter Card, 10/100/1000Mbps PCI Express NIC, Dual Realtek RTL8111H, Works with Windows and Linux, TAA Compliant
More info
Brand: STARTECH.COM
114.66 €
94.76 €
without VAT
Stock available: 10 units.
Get it
on the
September 29
/
October 1
SKU:
109056
PRC:
577614
EAN:
65030911047
PN:
ST1000SPEXD4T
Description
The StarTech.com ST1000SPEXD4T network card is an internal adapter with a PCI Express host interface that is installed in a PC or server to expand its network connections. It features two RJ-45 Ethernet LAN ports, so it allows two different network cables to be connected from a single card. It handles Fast Ethernet and Gigabit Ethernet over wired connection, with transfer speeds of 10, 100 and 1000 Mbit/s and a maximum of 1000 Mbit/s. Its Realtek RTL8111H chipset and support for 9000 Jumbo frames contribute to stable performance in demanding environments. It complies with the IEEE 802.3, IEEE 802.3ab, IEEE 802.3u and IEEE 802.3x standards, and includes IEEE Auto MDIX for automatic cable detection. Its LED indicators show the activity and link status of each port. It has a black colour, dimensions of 61 x 18 x 75 mm (width x height x depth) and a weight of 47 g, so it takes up little space inside the computer.
Specifications
Ports & interfaces
- Connectivity technology: Wired
- Host interface: PCI Express
- Interface: Ethernet
- Ethernet LAN (RJ-45) ports: 2
Network
- Maximum data transfer rate: 1000 Mbit/s
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
- Ethernet LAN: Yes
- Ethernet interface type: Fast Ethernet, Gigabit Ethernet
- Ethernet LAN data rates: 10, 100, 1000 Mbit/s
- Wake-on-LAN ready: Yes
- Auto MDIX IEEE: Yes
- Jumbo frames support: Yes
- Jumbo frames: 9000
Design
- Component for: PC/Server
- Product colour: Black
- Internal: Yes
- Chipset: Realtek RTL8111H
- LED indicators: Activity, Link
System requirements
- Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, W
- Linux operating systems supported: Yes
- Server operating systems supported: Windows Server 2016, Windows Server 2019, Windows Server 2022
Operational conditions
- Operating temperature (T-T): 5 - 70 °C
- Storage temperature (T-T): 0 - 80 °C
- Operating relative humidity (H-H): 10 - 80%
Weight & dimensions
- Width: 61 mm
- Depth: 75 mm
- Height: 18 mm
- Weight: 47 g
Packaging data
- Package width: 142 mm
- Package depth: 170 mm
- Package height: 30 mm
- Package weight: 111.2 g
Packaging content
- Mounting brackets included: Yes
- Quick installation guide: Yes
Technical details
- Compliance certificates: RoHS, Trade Agreements Act (TAA)
Logistics data
- Master (outer) case width: 685 mm
- Master (outer) case length: 345 mm
- Master (outer) case height: 306 mm
- Products per master (outer) case: 75 pc(s)
