TP-Link Omada 24-Port 2.5GBASE-T and 4-Port 10GE SFP+ L2+ Managed Switch with 16-Port PoE+ & 8-Port PoE++

Name: TP-Link Omada 24-Port 2.5GBASE-T and 4-Port 10GE SFP+ L2+ Managed Switch with 16-Port PoE+ & 8-Port PoE++
Brand: TP-LINK
SKU: 460743
Price: 917.28 EUR
Availability: InStock

More info

Brand: TP-LINK

917.28 €

784.00 € without VAT incl. 17 % VAT · Shipping to Luxembourg

Stock available: 8 units.

Get it on the October 7 / October 8

SKU: 102622 PRC: 460743 EAN: 4897098689738 PN: TL-SG3428XPP-M2

Description

The TP-Link Omada SG3428XPP-M2 managed switch, L2+ layer, comes in black and with dimensions of 440 x 44 x 330 mm (width x height x depth). It incorporates 24 2.5G copper Ethernet ports (100/1000/2500) and 4 slots for SFP+ modules, designed to link equipment and expand the network. Its RJ-45/Micro-USB console port allows access to the configuration via CLI and adjustment of the device's location parameters. Management is carried out via web or through the cloud, and includes system event logging and ARP inspection for traffic control. It offers VLAN support, link aggregation, spanning tree protocol and rate limiting, as well as quality of service (QoS). It also includes MIB support under references such as RFC1213, RFC2233, RFC1643, RFC1493, RFC2674 and RFC2819. It is a suitable option for setting up wired networks with centralised management in professional environments.

Specifications

Management features

Switch type: Managed
Switch layer: L2+
Quality of Service (QoS) support: Yes
Web-based management: Yes
Cloud-managed: Yes
ARP inspection: Yes
Configuring Location Settings (CLI): Yes
System event log: Yes
MIB support: RFC1213, RFC2233, RFC1643, RFC1493, RFC2674, RFC2819, RFC2021, RFC2620, RFC2618, RFC2925

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
2.5G Ethernet (copper) ports quantity: 24
SFP+ module slots quantity: 4
Console port: RJ-45/Micro-USB

Network

Spanning tree protocol: Yes
Head-of-line (HOL) blocking: Yes
Ethernet LAN data rates: 10,100,1000,2500,10000 Mbit/s
IPv4 routes: 48
IPv6 routes: 48
VLAN support: Yes
Virtual LAN features: MAC address-based VLAN, Port-based VLAN, Protocol-based VLAN, Stacked VLAN, Tagged VLAN, Voice VLAN
Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3
10G support: Yes
Port mirroring: Yes
Full duplex: Yes
Half duplex: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Rate limiting: Yes

Data transmission

Switching capacity: 200 Gbit/s
Forwarding rate: 148.8 Mpps
MAC address table: 32000 entries
Store-and-forward: Yes
Number of queues: 8
Static route: Yes
Number of static routes: 48
Number of IP interfaces: 32
Jumbo frames support: Yes
Jumbo frames: 9000
Packet buffer memory: 16 MB

Security

DHCP features: DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping
Access Control List (ACL): Yes
IGMP snooping: Yes
Security algorithms: HTTPS, SSH, SSH-2, SSL/TLS
Static port security: Yes
SSH/SSL support: Yes
Loop protection: Yes
BPDU filtering/protection: Yes
IP-MAC-Port binding: Yes
Authentication: Guest VLAN, MAC-based authentication, Port-based authentication
Password protection: Yes
Authentication type: AAA, IEEE 802.1x, RADIUS, TACACS+
Queue scheduling algorithms: SP, WRR+SP, Weighted Round Robin (WRR)

Multicast features

Multicast support: Yes
Multicast Listener Discovery (MLD) snooping: MLD v1/v2

Protocols

Management protocols: SNMP v1/v2c/v3
GARP VLAN Registration Protocol (GVRP): Yes
IPv4 & IPv6 features: IPv4/IPv6 access-control list (ACL), IPv6 ping, IPv6 portal, IPv6 tracert
