Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L2
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 8
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 8
- SFP+ module slots quantity: 4
- Fiber ports quantity: 4
- Fiber optic connector: SFP+
- Console port: RJ-45
Network
- Networking standards: IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 80
- 10G support: Yes
- Copper ethernet cabling technology: 10BASE-T, 10GBASE-T, 1000BASE-LX, 1000BASE-SX, 1000BASE-T
- Cable types supported: Cat5, Cat5e, Cat6
- Full duplex: Yes
- Flow control support: Yes
- Spanning tree protocol: Yes
- Auto-negotiation: Yes
- VLAN support: Yes
- Virtual LAN features: Port-based VLAN, Private VLAN
Data transmission
- Switching capacity: 96 Gbit/s
- Throughput: 48 Gbit/s
- MAC address table: 16000 entries
- Jumbo frames support: Yes
- Jumbo frames: 9000
Security
- DHCP features: DHCP client
- Access Control List (ACL): Yes
- IGMP snooping: Yes
Design
- Rack mounting: No
- Stackable: No
- Product colour: White
- Reset button: Yes
- LED indicators: Activity, Link, Power, Speed, Status
- Number of fans: 0 fan(s)
- Electromagnetic compatibility: CLASS A
Power
- Power source: AC
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption (max): 12.17 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 5 - 95%
Weight & dimensions
- Width: 290 mm
- Depth: 127 mm
- Height: 42.5 mm
- Weight: 1.15 kg
Packaging content
- Cables included: AC
- Quick start guide: Yes
Packaging data
- Package weight: 1.56 kg
Certificates
- Certification: CE, FCC, VCCI, BSMI
Logistics data
- Harmonized System (HS) code: 85176990
