Description
Specifications
Performance
- Suitable location: Processor
- Type: Cooler
- Fan diameter: 15 cm
- Supported processor sockets: LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 2011 (Socket R), LGA 2011-v3 (Socket
- Compatible processor series: AMD A, Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium®
- Rotational speed (min): 300 RPM
- Rotational speed (max): 1500 RPM
- Rotational speed with LNA (max): 1200 RPM
- Noise level (high speed): 24.6 dB
- Noise level with LNA (max): 19.2 dB
- Airflow: 140.2 m³/h
- Airflow with LNA (max): 115.5 m³/h
- Maximum air pressure: 2.08 mmH2O
- Maximum air pressure with LNA: 1.51 mmH2O
- Pulse-width modulation (PWM) support: Yes
- Bearing type: Self-Stabilising Oil-pressure Bearing (SSO)
Design
- Product colour: Black
- Base plate material: Copper
- Number of fans: 2 fan(s)
- Fins material: Aluminium
- Fan connector: 4-pin
Power
- Power supply: 1.56 W
- Rated voltage: 12 V
Weight & dimensions
- Width: 150 mm
- Depth: 161 mm
- Height: 165 mm
- Weight: 1.32 kg
- Heatsink weight: 980 g
- Package width: 190 mm
- Package depth: 268 mm
- Package height: 235 mm
- Package weight: 2.22 kg
Packaging content
- Package type: Box
- Cables included: Fan
Other features
- Heatsink dimensions (W x D x H): 150 x 135 x 160 mm
- Mean time to failure (MTTF): 150000 h
Logistics data
- Harmonized System (HS) code: 84733080
- Master (outer) case width: 415 mm
- Master (outer) case length: 509 mm
- Master (outer) case height: 573 mm
- Master (outer) case gross weight: 20.4 kg
