Description
The Mikrotik wAP ax LTE7 is a white access point designed for deploying wireless connectivity outdoors, with a maximum data transfer speed of 574 Mbit/s. It offers simultaneous operation on 2.4 GHz and 5 GHz, with MIMO to improve network performance. On the 2.4 GHz band it reaches 574 Mbit/s and on the 5 GHz band it reaches up to 1200 Mbit/s. It incorporates two RJ-45 Ethernet LAN ports compatible with speeds of 1000, 100 and 10 Mbit/s, as well as a Mini PCI Express slot. As for power, it supports Power over Ethernet (PoE), has a DC input jack and supports a DC voltage range of 12 to 57 V. Its maximum power consumption is 13 W and its mean time between failures reaches 200000 h. The antenna offers a maximum gain of 7 dBi and the device has IP66 protection. It is compatible with the network standards IEEE 802.3af, IEEE 802.3at, IEEE 802.11b, IEEE 802.11g, IEEE 802.
Specifications
Features
- 2.4 GHz: Yes
- 5 GHz: Yes
- Maximum data transfer rate: 574 Mbit/s
- Maximum data transfer rate (2.4 GHz): 574 Mbit/s
- Maximum data transfer rate (5 GHz): 1200 Mbit/s
- Ethernet LAN data rates: 1000, 10, 100 Mbit/s
- Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ax, IEEE 802.11a, IEEE 802.11ac
- MIMO: Yes
- Mean time between failures (MTBF): 200000 h
Ports & interfaces
- Ethernet LAN (RJ-45) ports: 2
- Mini PCI Express slots: 1
- DC-in jack: Yes
Power
- Power over Ethernet (PoE): Yes
- DC voltage range: 12 - 57 V
- Power consumption (max): 13 W
Design
- Product colour: White
- International Protection (IP) code: IP66
Antenna
- Antenna type: External
- Antenna gain level (max): 7 dBi
Performance
- Built-in processor: Yes
- Processor frequency: 800 MHz
- Internal memory: 256 MB
- Operating system installed: RouterOS
Certificates
- Compliance certificates: RoHS, CE, EAC
Mobile network
- 3G bands supported: 2100,900,850,1800 MHz
- 4G FDD-LTE bands supported: 2100,1800,850,2600,900,800,700 MHz
- 4G TDD-LTE bands supported: 2600,2300,2500 MHz
- SIM card slot: Yes
- SIM card type: MicroSIM
Packaging content
- Quantity per pack: 1 pc(s)
- AC adapter included: Yes
Operational conditions
- Operating temperature (T-T): -30 - 70 °C
