Dahua Technology WizMind NVR5216-EI network video recorder 1U Black
More info
Brand: DAHUA TECHNOLOGY
295.88 €Stock available: 0 units.
Unavailable
SKU:
108240
PRC:
505187
EAN:
6923172589798
PN:
NVR5216-EI
Description
The Dahua Technology WizMind NVR5216-EI is a black network video recorder (NVR), measuring 375 x 56 x 284.4 mm (width x height x depth) and weighing 1.57 kg. It features an embedded LINUX operating system and supports up to 16 video input channels, with a maximum resolution of 3840 x 2160 pixels and compatibility with 1920 x 1080, 1280 x 1024, 1280 x 720 and 1024 x 768 resolutions. It records in H.264, H.264+, H.265, H.265+ and M-JPEG formats, and offers manual and scheduled recording modes, as well as video motion detection and multi-screen. It supports two hard drives and the backup function, with two-way communication for remote management. It has four alarm input channels and two output channels, and serves up to 128 users. As for connectivity, it includes Power over Ethernet (PoE) in accordance with the IEEE 802.3af and IEEE 802.
Specifications
Performance
- Video input channels: 16 channels
- Alarm input channels: 4
- Alarm output channels: 2
- Maximum resolution: 3840 x 2160 pixels
- Supported resolutions: 3840 x 2160 1920 x 1080 1280 x 1024 1280 x 720 1024 x 768
- Number of users: 128 user(s)
- Two-way talk: Yes
- Video motion detection: Yes
- Multi-screen: Yes
- Video formats supported: H.264, H.264+, H.265, H.265+, M-JPEG
- Operating system installed: Embedded LINUX
- Backup function: Yes
- Recording modes: Manual, Schedule
Hard drive
- Number of HDDs supported: 2
Ports & interfaces
- Ethernet LAN (RJ-45) ports: 1
- Power over Ethernet (PoE): Yes
- Ethernet LAN data rates: 10, 100, 1000 Mbit/s
- Power over Ethernet (PoE) ports quantity: 16
- HDMI ports quantity: 1
- VGA (D-Sub) output ports: 1
- USB 2.0 ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
- RS-485 ports: 1
- RS-232 interface: Yes
- RS-232 ports: 1
- Networking standards: IEEE 802.3af, IEEE 802.3at
- Supported network protocols: HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search
Features
- Rack mounting: Yes
- Rack capacity: 1U
- Product colour: Black
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power over Ethernet (PoE) power per port: 25.5 W
- Total Power over Ethernet (PoE) budget: 130 W
Operational conditions
- Operating temperature (T-T): -10 - 55 °C
- Storage temperature (T-T): -20 - 60 °C
Technical details
- Compliance certificates: CE, Federal Communications Commission (FCC)
Weight & dimensions
- Package height: 366 mm
- Package weight: 2.73 kg
- Width: 375 mm
- Depth: 284.4 mm
- Height: 56 mm
- Weight: 1.57 kg
- Package width: 433 mm
- Package depth: 141 mm
