Name: DELL Precision 7540 Intel® Core™ i7 i7-9850H Mobile workstation 39.6 cm (15.6'') Full HD 16 GB DDR4-SDRAM 512 GB SSD NVIDIA Quadro T1000 Wi-Fi 6 (802.11ax) Windows 10 Pro Black
Brand: DELL
Price: 830.22 EUR
Availability: InStock

DELL Precision 7540 Intel® Core™ i7 i7-9850H Mobile workstation 39.6 cm (15.6'') Full HD 16 GB DDR4-SDRAM 512 GB SSD NVIDIA Quadro T1000 Wi-Fi 6 (802.11ax) Windows 10 Pro Black

More info

Brand: DELL

830.22 €

653.72 € without VAT

Description

Specifications

Design

Product type: Mobile workstation
Product colour: Black
Form factor: Clamshell

Display

Display diagonal: 39.6 cm (15.6")
Display resolution: 1920 x 1080 pixels
Touchscreen: No
HD type: Full HD
Panel type: IPS
LED backlight: Yes
Native aspect ratio: 16:9
Pixel pitch: 0.179 x 0.179 mm
Pixel density: 141 ppi
Dual-screen: No
Maximum refresh rate: 60 Hz
Contrast ratio (typical): 700:1

Processor

Processor manufacturer: Intel
Processor family: Intel® Core™ i7
Processor generation: 9th gen Intel® Core™ i7
Processor model: i7-9850H
Processor cores: 6
Processor threads: 12
Processor boost frequency: 4.6 GHz
Processor frequency: 2.6 GHz
System bus rate: 8 GT/s
Processor cache: 12 MB
Processor socket: BGA 1440
Processor lithography: 14 nm
Processor operating modes: 64-bit
Processor codename: Coffee Lake
Thermal Design Power (TDP): 45 W
Configurable TDP-down: 35 W
Tjunction: 100 °C
Maximum number of PCI Express lanes: 16
PCI Express slots version: 3.0
PCI Express configurations: 1x16, 2x8, 1x8+2x4

Memory

Internal memory: 16 GB
Internal memory type: DDR4-SDRAM
Memory clock speed: 2666 MHz
Memory form factor: SO-DIMM
Memory layout (slots x size): 2 x 8 GB
Memory slots: 4x SO-DIMM
Maximum internal memory: 128 GB

Storage

Total storage capacity: 512 GB
Storage media: SSD
Total SSDs capacity: 512 GB
Number of SSDs installed: 1
SSD capacity: 512 GB
SSD interface: PCI Express
SSD form factor: M.2
Optical drive type: No
Card reader integrated: Yes
Compatible memory cards: SD

Graphics

Discrete graphics card model: NVIDIA Quadro T1000
Discrete graphics card memory: 4 GB
Discrete graphics memory type: GDDR5
On-board graphics card: Yes
Discrete graphics card: Yes
On-board graphics card model: Intel® UHD Graphics 630
On-board graphics card base frequency: 350 MHz
On-board graphics card dynamic frequency (max): 1150 MHz
Maximum on-board graphics card memory: 64 GB
On-board graphics card DirectX version: 12.0
On-board graphics card OpenGL version: 4.5
On-board graphics card ID: 0x3E9B
Number of discrete graphics cards installed: 1
CUDA: Yes
CUDA cores: 768

Audio

Audio chip: Realtek ALC3281
Number of built-in speakers: 2
Speaker power: 2 W
Built-in microphone: Yes

Camera

Front camera: Yes
Front camera resolution (numeric): 0.92 MP
Front camera resolution: 1280 x 720 pixels
Front camera signal format: 720p
Front camera HD type: HD
Video capturing speed: 30 fps

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
HDMI version: 2.0
Mini DisplayPorts quantity: 1
Thunderbolt 3 ports quantity: 2
Combo headphone/mic port: Yes
SmartCard slot: Yes

Keyboard

Pointing device: DualPoint
Numeric keypad: Yes
Keyboard backlit: Yes
Windows keys: Yes

Software

Operating system architecture: 64-bit
Operating system language: Multilingual
Trial software: Microsoft Office
Operating system installed: Windows 10 Pro

Processor special features

Intel® Identity Protection Technology (Intel® IPT): Yes
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Intel® Turbo Boost Technology: 2.0
Enhanced Intel SpeedStep Technology: Yes
Thunderbolt™ 3 Technology: Yes
Intel® Clear Video HD Technology (Intel® CVT HD): Yes
Intel Clear Video Technology: Yes
Intel® InTru™ 3D Technology: Yes
Intel® Quick Sync Video Technology: Yes
Intel Flex Memory Access: Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel Trusted Execution Technology: Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel® Secure Key: Yes
Intel TSX-NI: Yes
Intel Stable Image Platform Program (SIPP): Yes
Intel® OS Guard: Yes
Intel Software Guard Extensions (Intel SGX): Yes
Intel 64: Yes
Execute Disable Bit: Yes
Idle States: Yes
Thermal Monitoring Technologies: Yes
Processor package size: 42 x 28 mm
Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0
CPU configuration (max): 1
Embedded options available: No
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel Virtualization Technology (VT-x): Yes
Processor ARK ID: 191047
Intel® My WiFi Technology (Intel® MWT): Yes

Battery

Battery technology: Lithium Polymer (LiPo)
Number of battery cells: 6
Battery capacity: 97 Wh
Battery voltage: 11.4 V
Battery recharge time: 4 h
Battery weight: 445 g

Power

AC adapter power: 180 W
AC adapter frequency: 50 - 60 Hz
AC adapter input voltage: 100 - 240 V
AC adapter output current: 9.23 A
AC adapter output voltage: 19.5 V
DC-in jack: Yes

Security

Cable lock slot: Yes
Cable lock slot type: Noble
Password protection: Yes

Operational conditions

Operating temperature (T-T): 0 - 35 °C
Storage temperature (T-T): -40 - 65 °C
Operating relative humidity (H-H): 20 - 80%
Storage relative humidity (H-H): 20 - 95%
Operating altitude: -15.2 - 3048 m
Non-operating altitude: -15.2 - 10668 m
Operating shock: 105 G
Non-operating shock: 40 G
Operating vibration: 0.26 G
Non-operating vibration: 1.37 G

Weight & dimensions

Width: 377.6 mm
Depth: 251.3 mm
Height (front): 2.5 cm
Height (rear): 3 cm
Weight: 2.52 kg

Packaging content

AC adapter included: Yes
Manual: Yes
Power cord included: Yes

Other features

Maximum internal memory (64-bit): 128 GB
