IP-COM Networks G1016D network switch Unmanaged L2 Gigabit Ethernet (10/100/1000) 1U Bronze
More info
Brand: IP-COM NETWORKS
61.49 €Stock available: 0 units.
Unavailable
SKU:
121687
PRC:
304105
EAN:
6932392831471
PN:
g1016d
Description
IP-COM Networks G1016D unmanaged L2 switch with 16 Gigabit Ethernet ports (10/100/1000) and a bronze steel casing, designed to expand your network easily. It offers a switching capacity of 32 Gbit/s and a forwarding rate of 23.8 Mpps, with a MAC address table of 8000 entries and store-and-forward mode. Supports full duplex, flow control, auto MDI/MDI-X, and auto-aging of MAC, compatible with Cat3, Cat4, Cat5 and Cat5e cables under IEEE 802.3, 802.3ab, 802.3u and 802.3x standards. Connect up to 16 network devices with 10BASE-T, 100BASE-TX or 1000BASE-T technology without the need for configuration, ideal for home environments or small offices.
Specifications
Management features
- Switch type: Unmanaged
- Switch layer: L2
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 16
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 16
Network
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
- 10G support: No
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T
- Cable types supported: Cat3, Cat4, Cat5, Cat5e
- Full duplex: Yes
- Flow control support: Yes
- Auto MDI/MDI-X: Yes
- MAC address auto-aging supported: Yes
Data transmission
- Switching capacity: 32 Gbit/s
- Forwarding rate: 23.8 Mpps
- MAC address table: 8000 entries
- Store-and-forward: Yes
Design
- Rack mounting: Yes
- Stackable: No
- Form factor: 1U
- Product colour: Bronze
- Housing material: Steel
- LED indicators: Activity, Link, Power
Performance
- Mean time between failures (MTBF): 100000 h
Power
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption (typical): 12 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
- Width: 297 mm
- Depth: 178 mm
- Height: 44 mm
Packaging content
- Manual: Yes
Certificates
- Certification: FCC、CE、RHOS
Logistics data
- Harmonized System (HS) code: 85176990
