Description
Dell E5-2609V3 processor from the Intel Xeon E5 v3 family, with 6 cores and a base frequency of 1.9 GHz. It is mounted on socket LGA 2011-v3, has a thermal design power of 85 W and is manufactured with 22 nm lithography. It supports DDR4-SDRAM memory at 1600 MHz in four-channel configuration, with a maximum capacity of 768 GB. It offers 40 PCI Express 3.0 buses and support for the AVX 2.0 instruction set. It includes Intel VT-d and VT-x virtualisation technology, along with Intel AES-NI and enhanced SpeedStep. It is aimed at the server segment and is compatible with PowerEdge R430, R530, R630, R730, R730XD and T430 systems, with a maximum configuration of two CPUs in 2S scalability.
Specifications
Processor
- Processor manufacturer: Intel
- Processor model: E5-2609V3
- Processor base frequency: 1.9 GHz
- Processor family: Intel Xeon E5 v3
- Processor cores: 6
- Processor socket: LGA 2011-v3
- Component for: Server/workstation
- Processor lithography: 22 nm
- Processor threads: 6
- System bus rate: 6.4 GT/s
- Processor operating modes: 64-bit
- Thermal Design Power (TDP): 85 W
- VID Voltage Range: 0.65 - 1.3 V
- Stepping: M1
- Bus type: QPI
- Number of QPI links: 2
- Memory bandwidth supported by processor (max): 51 GB/s
Memory
- Maximum internal memory supported by processor: 768 GB
- Memory types supported by processor: DDR4-SDRAM
- Memory clock speeds supported by processor: 1600 MHz
- Memory channels: Quad-channel
- ECC: Yes
Graphics
- On-board graphics card: No
Features
- Execute Disable Bit: Yes
- Idle States: Yes
- Thermal Monitoring Technologies: Yes
- Market segment: Server
- Maximum number of PCI Express lanes: 40
- PCI Express slots version: 3.0
- Supported instruction sets: AVX 2.0
- Scalability: 2S
- Physical Address Extension (PAE): Yes
- CPU configuration (max): 2
- Embedded options available: Yes
Processor special features
- Intel® Smart Cache: Yes
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Enhanced Intel SpeedStep Technology: Yes
- Intel Trusted Execution Technology: Yes
- Intel Enhanced Halt State: Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel Demand Based Switching: Yes
- Intel® Secure Key: Yes
- Intel® OS Guard: Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel® vPro™ Platform Eligibility: Yes
Operational conditions
- Tcase: 70.9 °C
Weight & dimensions
- Processor package size: 52.5 mm
Other features
- Intel® Virtualization Technology (Intel® VT): VT-d, VT-x
- Compatibility: PowerEdge R430 PowerEdge R530 PowerEdge R630 PowerEdge R730 PowerEdge R730XD PowerEdge T430 PowerEdge T630
