Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L2/L3
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- Traffic classification: Yes
- System event log: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 24
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 24
- Installed SFP modules quantity: 4
- Console port: RJ-45
Network
- Networking standards: IEEE 802.11j, IEEE 802.11k, IEEE 802.1Qav
- Cable types supported: Cat3, Cat4, Cat5
- Port mirroring: Yes
- IP routing: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Rate limiting: Yes
- Spanning tree protocol: Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
- MAC address auto-learning supported: Yes
- MAC address auto-aging supported: Yes
- VLAN support: Yes
- Virtual LAN features: Voice VLAN
- Number of VLANs: 4096
Optical fiber
- Fiber type: Multi-mode
Data transmission
- Switching capacity: 20 Gbit/s
- Forwarding rate: 14.88 Mpps
- MAC address table: 8000 entries
- Static route: Yes
- Jumbo frames support: Yes
- Jumbo frames: 9.6
- Packet buffer memory: 0.5 MB
Security
- DHCP features: DHCP Option 82, DHCP server, DHCP snooping
- IGMP snooping: Yes
- SSH/SSL support: Yes
- IP-MAC-Port binding: Yes
- Authentication: Port-based authentication
- Authentication type: AAA, TACACS+
Multicast features
- Multicast support: Yes
Protocols
- IPv4 & IPv6 features: IPv6 Telnet
Design
- Rack mounting: Yes
- Stackable: Yes
- Form factor: 1U
- Product colour: Black
- LED indicators: Activity, Link, Power, System
Performance
- Memory type: DDR-SDRAM
- Internal memory: 128 MB
- Flash memory: 16 MB
Power
- Power source: AC
- Power supply included: Yes
- AC input voltage: 100 - 240 V
Operational conditions
- Operating temperature (T-T): -10 - 50 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
- Width: 440 mm
- Depth: 204 mm
- Height: 44 mm
- Weight: 2.45 kg
Packaging data
- Package type: Box
- Package width: 500 mm
- Package depth: 290 mm
- Package height: 85 mm
- Package weight: 3.06 kg
