Description

Specifications

Ports & interfaces


  • Connectivity technology: Wired
  • Host interface: USB
  • Interface: Ethernet
  • Ethernet LAN (RJ-45) ports: 1
  • USB ports quantity: 4
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity: 3
  • USB version: 3.2 Gen 1 (3.1 Gen 1)

Network


  • Maximum data transfer rate: 5000 Mbit/s
  • Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
  • Ethernet LAN: Yes
  • Ethernet interface type: Gigabit Ethernet
  • Ethernet LAN data rates: 10, 100, 1000 Mbit/s
  • Cabling technology: 10/100/1000BaseT(X)
  • Wake-on-LAN ready: Yes
  • Auto MDIX IEEE: Yes
  • Full duplex: Yes
  • Jumbo frames support: Yes
  • Auto-negotiation: Yes
  • Jumbo frames: 9000
  • VLAN tagging: Yes

Design


  • Product colour: Black
  • Internal: No
  • Chipset: VIA/VLI - VL100, VIA/VLI - VL813, Realtek - RTL8153
  • Certification: CE, FCC

Power


  • USB powered: Yes

System requirements


  • Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, W
  • Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Ma
  • Linux operating systems supported: Yes
  • Server operating systems supported: Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2016, Windows Server 2019

Operational conditions


  • Operating temperature (T-T): 0 - 45 °C
  • Storage temperature (T-T): -10 - 70 °C
  • Operating relative humidity (H-H): 10 - 90%

Weight & dimensions


  • Width: 41 mm
  • Depth: 95 mm
  • Height: 17 mm
  • Weight: 44.9 g

Packaging data


  • Package width: 170 mm
  • Package depth: 142 mm
  • Package height: 30 mm
  • Package weight: 123 g

Technical details


  • Compliance certificates: RoHS

Logistics data


  • Harmonized System (HS) code: 85176990
  • Master (outer) case width: 330 mm
  • Master (outer) case length: 530 mm
  • Master (outer) case height: 310 mm
  • Products per master (outer) case: 60 pc(s)

Other features


  • Housing material: Plastic
  • Quick start guide: Yes
  • Flow control support: Yes
  • UASP support: Yes
  • Power supply: 60 W
