Description
Specifications
Management features
- Switch type: Managed
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 24
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 24
- SFP+ module slots quantity: 4
Network
- Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3
- 10G support: Yes
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Port mirroring: Yes
- Full duplex: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Spanning tree protocol: Yes
- VLAN support: Yes
- Virtual LAN features: Private VLAN, Tagged VLAN
- Number of VLANs: 256
Data transmission
- Switching capacity: 128 Gbit/s
- Throughput: 95.2 Mpps
- MAC address table: 16000 entries
- Jumbo frames support: Yes
- Jumbo frames: 10000
Security
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- Security algorithms: 802.1x RADIUS, HTTPS, SSL/TLS
- MAC address filtering: Yes
- SSH/SSL support: Yes
- Authentication: Port-based authentication
Multicast features
- Multicast support: Yes
Protocols
- Management protocols: SNMP (v1, v2c, v3)
Design
- Rack mounting: Yes
- Form factor: 1U
- Product colour: Black
- LED indicators: Yes
- Number of fans: 1 fan(s)
Performance
- Compatible operating systems: Windows 10, 8.1, 8, 7, Vista, XP, Windows 2003 / 2008 Server
- Noise level: 50 dB
- Buffer size: 2048 KB
- Maximum data transfer rate: 20000 Mbit/s
- Mean time between failures (MTBF): 450021 h
Power
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption (max): 25 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): 0 - 50 °C
Weight & dimensions
- Width: 440 mm
- Depth: 210 mm
- Height: 44.5 mm
- Weight: 2.64 kg
Packaging content
- Cables included: AC
- Quick start guide: Yes
- Rack mount kit: Yes
Packaging data
- Resource CD: Yes
Certificates
- Certification: CE FCC UL
Logistics data
- Harmonized System (HS) code: 85176990
