Description
The TP-Link EAP223 access point in white offers wireless connectivity in the 2.4 GHz and 5 GHz bands, with a maximum data transfer speed of 867 Mbit/s in the 5 GHz band and 450 Mbit/s in the 2.4 GHz band. It is compatible with the IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g and IEEE 802.11n network standards, and integrates Multi User MIMO technology to manage several connections at once. It incorporates band steering, which optimises the distribution of devices between both bands, and automatic channel selection and automatic channel scanner. It also supports VLAN support, quality of service (QoS), rate limiting and Wi-Fi Multimedia (WMM)/(WME). Powered via Power over Ethernet (PoE), it reaches a transmission power (CE) of 20, 23 dbm and (FCC) of 24, 22 dbm, and its dimensions are 205.5 x 37.1 x 181.5 mm (width x height x depth).
Specifications
Features
- MIMO: Yes
- MIMO type: Multi User MIMO
- Wi-Fi Multimedia (WMM)/(WME): Yes
- VLAN support: Yes
- Rate limiting: Yes
- Wireless isolation: Yes
- Band steering: Yes
- Quality of Service (QoS) support: Yes
- Transmitting power (CE): 20, 23 dBm
- Transmitting power (FCC): 24, 22 dBm
- 2.4 GHz: Yes
- 5 GHz: Yes
- 6 GHz: No
- Maximum data transfer rate: 867 Mbit/s
- Maximum data transfer rate (2.4 GHz): 450 Mbit/s
- Maximum data transfer rate (5 GHz): 867 Mbit/s
- Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
- Automatic channel selection: Yes
- Automatic channel scanning: Yes
Security
- Security algorithms: SSID
- MAC address filtering: Yes
- Number of SSID supported: 15
Management features
- Web-based management: Yes
- Syslog: Yes
- Management platform: Omada
Ports & interfaces
- Ethernet LAN (RJ-45) ports: 1
Power
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) type supported: Active PoE, Passive PoE
- Output voltage: 48 V
- Power consumption (typical): 9.7 W
Design
- Placement: Ceiling, Wall
- Product colour: White
- Reset button: Yes
- LED indicators: Power
Antenna
- Antenna type: Internal
- Antenna direction type: Omni-directional
- Antennas quantity: 3
Performance
- Compatible operating systems: Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
Certificates
- Certification: CE, FCC, RoHS
Weight & dimensions
- Width: 205.5 mm
- Depth: 181.5 mm
- Height: 37.1 mm
Packaging content
- Quantity per pack: 1 pc(s)
- Cables included: AC
- Mounting kit: Yes
- Quick start guide: Yes
Operational conditions
- Operating relative humidity (H-H): 10 - 90%
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Storage relative humidity (H-H): 5 - 90%
