Description
Specifications
Management features
- Switch type: Unmanaged
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 5
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 5
- Power connector: DC-in jack
Network
- Networking standards: IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
- 10G support: No
- Full duplex: Yes
- Flow control support: Yes
- Auto MDI/MDI-X: Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
- Auto-negotiation: Yes
Data transmission
- Supported data transfer rates: 10/100/1000Mbps
- Switching capacity: 10 Gbit/s
- Forwarding rate: 7.4 Mpps
- MAC address table: 2000 entries
- Store-and-forward: Yes
- Maximum data transfer rate: 2 Gbit/s
- Jumbo frames support: Yes
- Jumbo frames: 16000
- Packet buffer memory: 1 MB
Security
- IGMP snooping: Yes
Protocols
- Switching protocols: CSMA/CD
Design
- Product colour: Black
- LED indicators: Yes
Power
- Power source: DC
- Power supply included: Yes
- Input current: 0.6 A
- Input voltage: 9 V
- Power consumption (max): 2.3 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Other features
- Connectivity technology: Wired
- Wi-Fi: No
- Power LED: Yes
- Ethernet LAN: Yes
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
- Heat dissipation: 7.83 BTU/h
Weight & dimensions
- Width: 100 mm
- Depth: 98 mm
- Height: 25 mm
Packaging content
- User guide: Yes
- Rack mount kit: Yes
Packaging data
- Package type: Box
- Package width: 125 mm
- Package depth: 128 mm
- Package height: 92 mm
- Package weight: 370 g
Certificates
- Certification: CE, FCC, RoHS
