Description
The Salicru SLC-10000-TWIN PRO2 UPS protects critical equipment with an input current total harmonic distortion of 4% and an input operating voltage starting at 110 V. It operates with a single phase for both input and output, and delivers a precisely regulated output voltage with 1% accuracy, within a range from 208 V to 240 V. Its efficiency reaches 94% and ECO mode allows consumption to be adjusted according to the connected load. Output frequency regulation is 4 Hz, with 0.1 Hz synchronisation when operating without mains, and the noise level stands at 60 dB. It incorporates emergency shutdown and is maintenance-free, with a weight of 85 kg, black colour and dimensions of 250 x 576 x 592 mm (width x height x depth). Output total harmonic distortion remains at 4%, with 1% on linear load and 4% on non-linear load.
Specifications
Features
- Output power factor: 1
- Crest factor: 3:1
- ECO mode: Yes
- Emergency Power Off (EPO): Yes
- Overload capacity (10 minutes): 110%
- Overload capacity (1 minute): 130%
- Output voltage Total Harmonic Distortion (THD): 4%
- Input current Total Harmonic Distortion (THD): 4%
- Total Harmonic Distortion (THD) (linear load): 1%
- Total Harmonic Distortion (THD) (non-linear load): 4%
- Noise level: 60 dB
- Surge protection: Yes
- Power protection features: Under voltage
- Maximum number of paralleling UPSs: 3
- Synchronisation with mains: 4 Hz
- Synchronisation without mains: 0.1 Hz
- Temperature voltage compensation: Yes
- Maintenance-free: Yes
- UPS topology: Double-conversion (Online)
- Output power capacity: 10 kVA
- Output power: 10000 W
- Input operation voltage (min): 110 V
- Input operation voltage (max): 276 V
- Input frequency: 50/60 Hz
- Output operation voltage (min): 208 V
- Output operation voltage (max): 240 V
- Output frequency regulation: 4 Hz
- Output voltage regulation: 1%
- Number of input phases: 1
- Number of output phases: 1
- Efficiency: 94%
- Input power factor: 0.99
Ports & interfaces
- AC outlet types: C13 coupler
- AC outlets quantity: 2 AC outlet(s)
- Number of output IEC jumpers: 2
- USB port: Yes
- USB 2.0 ports quantity: 1
- Serial interface: Yes
- Serial interface type: RS-232
- RS-232 ports: 1
- Parallel ports quantity: 3
- Emergency Power Off (EPO) connector: Yes
Battery
- Battery technology: Lead-Calcium (Pb-Ca)
- Battery recharge time: 7 h
- Automatic battery test: Yes
- Cold start: Yes
- Off-mode charging: Yes
Design
- Form factor: Tower
- Cooling type: Active
- Built-in fan: Yes
- Product colour: Black
- Display type: LCD
- LED indicators: Yes
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 0 - 95%
- Operating altitude: 0 - 5000 m
Safety regulation & standards
- Safety: EN 62040-1; EN 60950-1
Weight & dimensions
- Width: 250 mm
- Depth: 592 mm
- Height: 576 mm
- Weight: 85 kg
Logistics data
- Harmonized System (HS) code: 85078000
Other features
- I/O ports: Intelligent slot
- Battery type: AGM
- Bypass: Hybrid, Nill
