Description
QNAP TS-464U-RP, NAS, Rack (1U), Intel® Celeron®, N5095, 8 GB, DDR4
Specifications
Storage
- Supported storage drive interfaces: Serial ATA II, Serial ATA III
- Storage drive sizes supported: 2.5, 3.5"
- RAID support: Yes
- RAID levels: 0, 6, 1, JBOD, 5, 10
- Online RAID migration: Yes
- Online RAID expansion: Yes
- RAID rebuild: Yes
- Hot-swap drive bays: Yes
- Supported file systems: FAT32, exFAT, HFS+, NTFS, ext3, ext4
- Storage drives installed: No
- Total installed storage capacity: 0 TB
- Number of storage drives supported: 4
- Installed storage drive type: No
- Supported storage drive types: HDD & SSD
- Disk roaming: Yes
Processor
- Processor manufacturer: Intel
- Processor family: Intel® Celeron®
- Processor model: N5095
- Processor frequency: 2 GHz
- Processor boost frequency: 2.9 GHz
- Processor cores: 4
- Processor threads: 4
- CPU configuration (max): 1
- On-board graphics card model: Intel® UHD Graphics
Memory
- Internal memory: 8 GB
- Internal memory type: DDR4
- Maximum RAM supported: 16 GB
- Memory slots: 2
- Memory form factor: SO-DIMM
- Flash memory: 4000 MB
Network
- Ethernet LAN: Yes
- Ethernet LAN data rates: 10, 1000, 2500, 100 Mbit/s
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T, 2500BASE-T
- DHCP server: Yes
- Jumbo frames support: Yes
- iSCSI support: Yes
- Wake-on-LAN ready: Yes
- Dynamic DNS (DDNS): Yes
Ports & interfaces
- USB port: Yes
- USB 2.0 ports quantity: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- HDMI ports quantity: 1
- HDMI version: 1.4b
- Ethernet LAN (RJ-45) ports: 2
- Concurrent connections: 1500
- PCI Express x2 (Gen 3.x) slots: 1
Design
- Chassis type: Rack (1U)
- Cooling type: Active
- Product colour: Aluminium, Black
- Number of fans: 2 fan(s)
- Fan diameter: 4 cm
- LED indicators: HDD, Status, Power, LAN
Performance
- Type: NAS
- Device class: Small & Medium Business
- Backup function: Yes
- Backup features: Cloud, iSCSI LUN
- Buzzer: Yes
- Multilingual support: Yes
- Snapshot: Yes
- Management protocols: SNMP V2, V3
- Security algorithms: 256-bit AES, FIPS 140-2, HTTPS, SNMPv2, SNMPv3, SSH
- Access Control List (ACL): Yes
- Reset button: Yes
- On/off switch: Yes
- Built-in FTP server: Yes
- Browser supported: Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox
- System log: Yes
- Hot spare: Yes
- Disk scan: Yes
- S.M.A.R.T. support: Yes
- Share folder: CIFS/SMB
Software
- Operating system installed: QNAP Turbo System
- Operating system version: 5.0.1
- Windows operating systems supported: Windows 10, Windows 8, Windows 7, Windows 11
- Linux operating systems supported: Ubuntu 14.04
- Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Ma
- Server operating systems supported: Windows Server 2019, Windows Server 2012 R2, Windows Server 2008 R2, Windows Server 2016, Windows Server 2012
- Other operating systems supported: Solaris 10
Power
- Power supply location: Built-in
- Power supply unit (PSU) capacity: 250 W
- Number of power supply units: 2
- Redundant power supply (RPS) support: Yes
- Power consumption (typical): 51.404 W
- Power consumption (sleep): 37.469 W
- AC input voltage: 100 - 240 V
- Fan voltage: 12 V
Weight & dimensions
- Width: 430 mm
- Depth: 479 mm
- Height: 43.3 mm
- Weight: 8.12 kg
- Package weight: 10.1 kg
Packaging content
- Cables included: AC, LAN (RJ-45)
- Power cables quantity: 2
- Number of screws: 84
Processor special features
- Enhanced Intel SpeedStep Technology: Yes
- Idle States: Yes
- Intel 64: Yes
- Intel Trusted Execution Technology: No
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 5 - 95%
- Storage temperature (T-T): -20 - 70 °C
- Storage relative humidity (H-H): 5 - 95%
Logistics data
- Harmonized System (HS) code: 84714100
