Description
Specifications
Ports & interfaces
- Connectivity technology: Wired
- Host interface: PCI Express
- Interface: Ethernet
- Ethernet LAN (RJ-45) ports: 1
- PCI version: 3.1
Network
- Maximum data transfer rate: 5000 Mbit/s
- Networking standards: IEEE 1588, IEEE 802.1as, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u
- Ethernet LAN: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
- Ethernet LAN data rates: 10, 100, 1000, 2500 Mbit/s
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T, 2500BASE-T
- Wake-on-LAN ready: Yes
- Jumbo frames support: Yes
- Jumbo frames: 9500
- Supported network protocols: IPv4, IPv6
Design
- Component for: PC/Server
- Product colour: Green
- Internal: Yes
- Country of origin: China
System requirements
- Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, W
Operational conditions
- Operating temperature (T-T): 0 - 45 °C
- Storage temperature (T-T): -40 - 85 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 10 - 90%
Sustainability
- Sustainability compliance: Yes
Weight & dimensions
- Width: 72 mm
- Depth: 55 mm
- Height: 20 mm
- Weight: 40 g
Packaging data
- Package width: 183 mm
- Package depth: 152 mm
- Package height: 30 mm
- Package weight: 150 g
Packaging content
- Mounting brackets included: Yes
- Resource CD: Yes
- Quick installation guide: Yes
Technical details
- Compliance certificates: CE, Federal Communications Commission (FCC), RoHS
Logistics data
- Products per master (outer) case: 60 pc(s)
- Harmonized System (HS) code: 8517620090
- Pallet gross width: 120 cm
- Pallet gross length: 80 cm
- Pallet gross height: 189.4 cm
- Master (outer) cases per pallet: 19 pc(s)
- Master (outer) case width: 490 mm
- Master (outer) case length: 340 mm
- Master (outer) case height: 350 mm
- Master (outer) case gross weight: 10 kg
Other features
- Buffer size: 40 KB
