Description
Specifications
Management features
- Switch type: Managed
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 8
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
- Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
- Port mirroring: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- VLAN support: Yes
- Number of VLANs: 8
Data transmission
- Switching capacity: 16 Gbit/s
- Forwarding rate: 11.9 Mpps
- MAC address table: 4000 entries
- Store-and-forward: Yes
- Jumbo frames support: Yes
- Jumbo frames: 9000
- Packet forwarding rate (1 Gbps): 1488000 pps
- Packet forwarding rate (100 Mbps): 148800 pps
- Packet forwarding rate (10 Mbps): 14880 pps
- Packet buffer memory: 1.53 MB
Security
- IGMP snooping: Yes
- Loop protection: Yes
- Queue scheduling algorithms: Strict Priority Queue (SPQ), WFQ
Multicast features
- Multicast support: Yes
- Multicast features: Multicast traffic suppression
Design
- Product colour: Black
- Housing material: Metal
- Reset button: Yes
- LED indicators: Yes
- Wall mountable: Yes
Performance
- Fanless: Yes
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
- Width: 155 mm
- Depth: 85 mm
- Height: 26 mm
- Weight: 325 g
Certificates
- Certification: CE, FCC, BSMI
