Description
Specifications
Power
- Total power: 800 W
- AC input voltage: 100 - 240
- AC input frequency: 50 - 60
- Maximum input current (@110V): 8 A
- Maximum input current (@220V): 4 A
- Power Factor Correction (PFC) type: Active
- Combined power (+3.3V): 132 W
- Combined power (+12V): 684 W
- Combined power (+5V): 132 W
- Combined power (-12V): 6 W
- Combined power (+5Vsb): 12.5 W
- Max output current (+3.3V): 18 A
- Max output current (+12V1): 22 A
- Max output current (+12V2): 22 A
- Max output current (+12V4): 22 A
- Max output current (+12V3): 22 A
- Max output current (+5V): 18 A
- Max output current (-12V): 0.5 A
- Max output current (+5Vsb): 2.5 A
- Power Good signal delay range: 100 - 500 ms
- Efficiency: 85%
- Power protection features: Over power, Over voltage, Short circuit, Under voltage
Cooling
- Fan diameter: 14 cm
- Cooling type: Active
- Number of fans: 1 fan(s)
- Fan location: Top
Ports & interfaces
- Motherboard power connector: 20+4 pin ATX
- Number of SATA power connectors: 6
- Peripheral (Molex) power connectors (4-pin): 4
- PCI Express power connectors (6+2 pin): 2
- CPU power connector (4+4 pin): Yes
- Floppy disk drive connector: Yes
- Floppy drive power connector: 1
- PCI Express connector: Yes
Performance
- Purpose: PC/server
- Power supply unit (PSU) form factor: ATX
- ATX version: 2.31
- Noise level: 25 dB
- On/off switch: Yes
- Mean time between failures (MTBF): 100000 h
Design
- Colour of product: Black
Technical details
- Cables included: AC
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
- Weight: 2.1 kg
Certificates
- 80 PLUS certification: 80 PLUS Bronze
- RoHS compliance: Yes
- Certification: CE, WEEE
Packaging data
- Package type: Box
Packaging content
- Manual: Yes
